Product Summary
The ADP3303ARZ-3.3REEL is a precision low dropout anyCAP voltage regulator. The device stands out from the conventional LDOs with a novel architecture, an enhanced process and a new package. Its patented design requires only a 0.47 µF output capacitor for stability.
Parametrics
ADP3303ARZ-3.3REEL absolute maximum ratings: (1)Input Supply Voltage:–0.3 V to +16 V; (2)Shutdown Input Voltage:–0.3 V to +16 V; (3)Error Flag Output Voltage:–0.3 V to +16 V; (4)Noise Bypass Pin Voltage:–0.3 V to +5 V; (5)Power Dissipation:Internally Limited; (6)Operating Ambient Temperature Range:–20℃ to +85℃; (7)Operating Junction Temperature Range:–20℃ to +125℃; (8)Storage Temperature Range:–65℃ to +150℃; (9)Lead Temperature Range (Soldering 10 sec): +300℃.
Features
ADP3303ARZ-3.3REEL features: (1)High Accuracy Over Line and Load ±0.8% @ at +25℃, ±1.4% Over Temperature; (2)Ultralow Dropout Voltage: 180 mV (Typ) @ 200 mA; (3)Requires Only CO = 0.47 μF for Stability; (4)anyCAP = Stable with All Types of Capacitors(Including MLCC); (5)3.2 V to 12 V Supply Range; (6)Current and Thermal Limiting; (7)Low Noise; (8)Dropout Detector; (9)Low Shutdown Current: < 1 mA; (10)Thermally Enhanced SO-8 Package; (11)Excellent Line and Load Regulation Performance.
